CCTV Security Pros Firmware Updates, In order to do a firmware update you must first identify the EXACT model number of your DVR or NVR unit. The model number can be found on the sticker located on the bottom or side of the unit. All CCTV Security Pros model numbers begin with the prefix “CSP” (Example, CSP-XXXX). Please match your model number to the list provided below. You will also need to locate your order confirmation email to determine when the unit was purchased. Once you have identified the correct model number and firmware please continue by following the instructions below.

UPDATING YOUR SECURITY CAMERA FIRMWARE



Upgrading Your Firmware

Please identify the correct model from the list of firmware provided below.

Please select the appropriate link and download the .bin file. Once the download is completed copy the .bin file to a USB Flash/Thumb Drive. We suggest formatting your USB drive to FAT32 before attempting the update.

**Note : Units with Build Dates of 2013 or earlier may require you to rename the file to “update.bin” before launching the upgrade.

Once the .bin file has been transferred onto your drive you can insert the USB Drive into either of the two USB ports found on your unit. One can be found on the front panel and one can be found on the rear of the unit.

Once the drive is inserted into the unit go to the following menu:

Main Menu –> Setting –> System –> Upgrade. Click Start. Find and select the .bin file you transferred to the USB Drive and Click Start.

*NOTE – On select models you will need to go to:

Main Menu–> Info –> Version –> Upgrade

CCTV Security Pros Firmware Updates

The unit will now begin upgrading to the latest Firmware Revision that is available for your device. Once completed the system will reboot. After the reboot we recommend doing the following:

1) Remove the USB Drive from your system.

2) Change your passwords on your “admin” account. For assistance in altering your password please follow this link: https://www.cctvsecuritypros.com/content/pdfs/password-account-settings.pdf

2014 PURCHASE DATE
DVR
CSP-LITE4	https://drive.google.com/file/d/0BxHOdABdpZ11c2tWVlNJdl9kMWM/view?usp=sharing
CSP-LITE4 (alternative)	https://drive.google.com/file/d/0BxHOdABdpZ11M05Fd1dpUTRWLTg/view?usp=sharing
CSP-LITE8	https://drive.google.com/file/d/0BxHOdABdpZ11c2tWVlNJdl9kMWM/view?usp=sharing
CSP-LITE8 (alternative)	https://drive.google.com/file/d/0BxHOdABdpZ11M05Fd1dpUTRWLTg/view?usp=sharing
CSP-LITE16	https://drive.google.com/file/d/0BxHOdABdpZ11RmkzVUg0Q051MEU/view?usp=sharing
CSP-LITE16 (alternative)	https://drive.google.com/file/d/0BxHOdABdpZ11X2J3WGhmcHdhRHM/view?usp=sharing
CSP-4PRO960H	https://drive.google.com/open?id=0BxHOdABdpZ11bGgtMk1Lc0NHYTg
CSP-4PRO960H (alternative)	https://drive.google.com/open?id=0BxHOdABdpZ11S1EzQmIyMTUwOVE
CSP-8PRO960H	https://drive.google.com/open?id=0BxHOdABdpZ11bGgtMk1Lc0NHYTg
CSP-8PRO960H (alternative)	https://drive.google.com/open?id=0BxHOdABdpZ11RzdFUlRQRksxWEE
CSP-16PRO960H	https://drive.google.com/open?id=0BxHOdABdpZ11bU8wNTNNN2JZMlE
CSP-16PRO960H (alternative)	https://drive.google.com/open?id=0BxHOdABdpZ11VndLSERKaTl5ZGc
CSP-4XTR960H	https://drive.google.com/open?id=0BxHOdABdpZ11bGgtMk1Lc0NHYTg
CSP-8XTR960H	https://drive.google.com/open?id=0BxHOdABdpZ11bGgtMk1Lc0NHYTg
CSP-16XTR960H	https://drive.google.com/open?id=0BxHOdABdpZ11bGgtMk1Lc0NHYTg
CSP-EXTREME32HD	https://drive.google.com/open?id=0BxHOdABdpZ11c1oyWDZfN1NVMzQ
CSP-CVIMINI4	https://drive.google.com/open?id=0BxHOdABdpZ11b0FSSW5PSFVvVGc
CSP-CVIMINI	https://drive.google.com/open?id=0BxHOdABdpZ11NFdfd3BxQXN4bVU
CSP-4PROCVI	https://drive.google.com/open?id=0BxHOdABdpZ11akZvT2M3WnM0Zk0
CSP-8PROCVI	https://drive.google.com/open?id=0BxHOdABdpZ11b20ydmtjako3RzA
CSP-16PROCVI	https://drive.google.com/open?id=0BxHOdABdpZ11b20ydmtjako3RzA
NVR
CSP-4PROPOE	https://drive.google.com/open?id=0BxHOdABdpZ11Ym1kVnZhVkNxaXc
CSP-8PROPOE	https://drive.google.com/open?id=0BxHOdABdpZ11THZHUS1DMzdqZkE
CSP-EXTREME16NVR	https://drive.google.com/open?id=0BxHOdABdpZ11THZHUS1DMzdqZkE
CSP-EXTREME32NVR	https://drive.google.com/open?id=0BxHOdABdpZ11THZHUS1DMzdqZkE
CSP-XTRPOE16	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
HYBRID
CSP-EXTREME16HBR	https://drive.google.com/open?id=0BxHOdABdpZ11Mm5tTm4zanJnVGc
CSP-4HBR960H	https://drive.google.com/open?id=0BxHOdABdpZ11VFBpNXNmYTFjU2M
CSP-8HBR960H	https://drive.google.com/open?id=0BxHOdABdpZ11VFBpNXNmYTFjU2M
CSP-16HBR960H	https://drive.google.com/open?id=0BxHOdABdpZ11VFBpNXNmYTFjU2M
2015 PURCHASE DATE
DVR
CSP-LITE4	https://drive.google.com/file/d/0BxHOdABdpZ11c2tWVlNJdl9kMWM/view?usp=sharing
CSP-LITE4 (alternative)	https://drive.google.com/file/d/0BxHOdABdpZ11M05Fd1dpUTRWLTg/view?usp=sharing
CSP-LITE8	https://drive.google.com/file/d/0BxHOdABdpZ11c2tWVlNJdl9kMWM/view?usp=sharing
CSP-LITE8 (alternative)	https://drive.google.com/file/d/0BxHOdABdpZ11M05Fd1dpUTRWLTg/view?usp=sharing
CSP-LITE16	https://drive.google.com/file/d/0BxHOdABdpZ11RmkzVUg0Q051MEU/view?usp=sharing
CSP-LITE16 (alternative)	https://drive.google.com/file/d/0BxHOdABdpZ11X2J3WGhmcHdhRHM/view?usp=sharing
CSP-4PRO960H	https://drive.google.com/open?id=0BxHOdABdpZ11S1EzQmIyMTUwOVE
CSP-8PRO960H	https://drive.google.com/open?id=0BxHOdABdpZ11RzdFUlRQRksxWEE
CSP-16PRO960H	https://drive.google.com/open?id=0BxHOdABdpZ11bU8wNTNNN2JZMlE
CSP-16PRO960H (alternative)	https://drive.google.com/open?id=0BxHOdABdpZ11cHg2S1pPUXM2cm8
CSP-4XTR960H	https://drive.google.com/open?id=0BxHOdABdpZ11QXY5R1N5SWc3Z0U
CSP-8XTR960H	https://drive.google.com/open?id=0BxHOdABdpZ11WkhZeHBEbUx6ZUE
CSP-16XTR960H	https://drive.google.com/open?id=0BxHOdABdpZ11UTlVOV9CUDdvX0k
CSP-CVIMINI4	https://drive.google.com/open?id=0BxHOdABdpZ11b0FSSW5PSFVvVGc
CSP-CVIMINI8	https://drive.google.com/open?id=0BxHOdABdpZ11NFdfd3BxQXN4bVU
CSP-4PROCVI	https://drive.google.com/open?id=0BxHOdABdpZ11akZvT2M3WnM0Zk0
CSP-8PROCVI	https://drive.google.com/open?id=0BxHOdABdpZ11b20ydmtjako3RzA
CSP-16PROCVI	https://drive.google.com/open?id=0BxHOdABdpZ11b20ydmtjako3RzA
CSP-16PROCVI (alternative)	https://drive.google.com/open?id=0BxHOdABdpZ11cHg2S1pPUXM2cm8
CSP-EXTREME32HD	https://drive.google.com/open?id=0BxHOdABdpZ11U2ZnbUR4OEl0a28
CSP-CVIMINI4	https://drive.google.com/open?id=0BxHOdABdpZ11cDVTMExBbm1YLXc
CSP-CVIMINI8	https://drive.google.com/open?id=0BxHOdABdpZ11akZvT2M3WnM0Zk0
CSP-32XTRCVI	https://drive.google.com/file/d/0BxHOdABdpZ11N1AwdWdUUkJHMTg/view?usp=sharing
CSP-4PRO	https://drive.google.com/open?id=0BxHOdABdpZ11akZvT2M3WnM0Zk0
CSP-8PRO	https://drive.google.com/open?id=0BxHOdABdpZ11akZvT2M3WnM0Zk0
CSP-16PRO	https://drive.google.com/open?id=0BxHOdABdpZ11cHg2S1pPUXM2cm8
CSP-4XTR	https://drive.google.com/open?id=0BxHOdABdpZ11akZvT2M3WnM0Zk0
CSP-8XTR	https://drive.google.com/open?id=0BxHOdABdpZ11akZvT2M3WnM0Zk0
CSP-16XTR	https://drive.google.com/open?id=0BxHOdABdpZ11cHg2S1pPUXM2cm8
CSP-32XTR	https://drive.google.com/file/d/0BxHOdABdpZ11N1AwdWdUUkJHMTg/view?usp=sharing
HYBRIDS
CSP-4HBR960H	https://drive.google.com/open?id=0BxHOdABdpZ11bGgtMk1Lc0NHYTg
CSP-8HBR960H	https://drive.google.com/open?id=0BxHOdABdpZ11bGgtMk1Lc0NHYTg
CSP-16HBR960H	https://drive.google.com/open?id=0BxHOdABdpZ11bGgtMk1Lc0NHYTg
CSP-4TRIBRID	https://drive.google.com/file/d/0BxHOdABdpZ11N1AwdWdUUkJHMTg/view?usp=sharing
CSP-8TRIBRID	https://drive.google.com/file/d/0BxHOdABdpZ11N1AwdWdUUkJHMTg/view?usp=sharing
CSP-16TRIBRID	https://drive.google.com/file/d/0BxHOdABdpZ11N1AwdWdUUkJHMTg/view?usp=sharing
NVR
CSP-NVRCUBE	https://drive.google.com/open?id=0BxHOdABdpZ11ZzNKdlRmTEttSTQ
CSP-4PROPOE	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
CSP-8PROPOE	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
CSP-XTRPOE16	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
CSP-EXTREME16NVR	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
CSP-EXTREME32NVR	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
CSP-XTRPOE16	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
CSP-XTRNVR16	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
CSP-XTRNVR32	https://drive.google.com/open?id=0BxHOdABdpZ11U3VsTVdSd25zeWc
2016 – 2019 PURCHASE DATES
DVR
CSP-4LITE	https://drive.google.com/open?id=0BxHOdABdpZ11cDVTMExBbm1YLXc
CSP-8LITE	https://drive.google.com/open?id=0BxHOdABdpZ11cDVTMExBbm1YLXc
CSP-16LITE	https://drive.google.com/open?id=0BxHOdABdpZ11akZvT2M3WnM0Zk0
CSP-4LITE.5	https://drive.google.com/open?id=0BxHOdABdpZ11aEVXeURTd3lpZXM
CSP-8LITE.5	https://drive.google.com/open?id=0BxHOdABdpZ11UXdFakdicVR1S2s
CSP-16LITE.5	https://drive.google.com/open?id=0BxHOdABdpZ11RXdfZkM0aHNqZzA
CSP-4LITE.X5	https://drive.google.com/open?id=0BxHOdABdpZ11Z0ItM0V5ZHhMaDA
CSP-8LITE.X5	https://drive.google.com/open?id=0BxHOdABdpZ11UEw2TkEzeWVRdFU
CSP-16LITE.X5	https://drive.google.com/open?id=0BxHOdABdpZ11eDZxUWU3cmtRcWs
CSP-4PRO	https://drive.google.com/open?id=0BxHOdABdpZ11akZvT2M3WnM0Zk0
CSP-8PRO	https://drive.google.com/open?id=0BxHOdABdpZ11cHg2S1pPUXM2cm8
CSP-16PRO	https://drive.google.com/open?id=0BxHOdABdpZ11cHg2S1pPUXM2cm8
CSP-4PRO.7	https://drive.google.com/open?id=0BxHOdABdpZ11VjYwaDBrZHNLSnM
CSP-8PRO.7	https://drive.google.com/open?id=0BxHOdABdpZ11RXdfZkM0aHNqZzA
CSP-16PRO.7	https://drive.google.com/open?id=0BxHOdABdpZ11b1JaVTRtQWExQ2s
CSP-4PRO.X7	https://drive.google.com/open?id=0BxHOdABdpZ11UEw2TkEzeWVRdFU
CSP-8PRO.X7	https://drive.google.com/open?id=0BxHOdABdpZ11OExRUUNIVkJsWWc
CSP-16PRO.X7	https://drive.google.com/open?id=0BxHOdABdpZ11c2s1MnNoMlp2QTA
CSP-16TRIBRID	https://drive.google.com/file/d/0BxHOdABdpZ11N1AwdWdUUkJHMTg/view?usp=sharing
CSP-16XTR	https://drive.google.com/open?id=0BxHOdABdpZ11cHg2S1pPUXM2cm8
CSP-32XTR	https://drive.google.com/file/d/0BxHOdABdpZ11N1AwdWdUUkJHMTg/view?usp=sharing
CSP-32XTR.X5	https://drive.google.com/open?id=18BBt7UqFBhbW8xqQKOGeu76JPMrUelFC
NVR
CSP-NVRWIFI	https://drive.google.com/open?id=0BxHOdABdpZ11MUdkVVBLbENDR0E
CSP-NVRCUBE	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
CSP-NVRPOE4	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
CSP-NVRPOE4-4KS	https://drive.google.com/open?id=1CgTtWiWeFrURT_Bs35aNWgO4MrCQPliN
CSP-PROPOE8	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
CSP-XTRPOE16	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
CSP-XTRNVR16	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
CSP-XTRNVR32	https://drive.google.com/open?id=0BxHOdABdpZ11UVhxeXJ6OVJjUzA
CSP-PROPOE8-4K	https://drive.google.com/open?id=1lLLuP3qUgee4rCiUZu7GEMUAteXWqmaI
CSP-XTRPOE16-4K	https://drive.google.com/open?id=1lLLuP3qUgee4rCiUZu7GEMUAteXWqmaI
CSP-XTRNVR16-4K	https://drive.google.com/open?id=1lLLuP3qUgee4rCiUZu7GEMUAteXWqmaI
CSP-PROPOE8-4KS	https://drive.google.com/open?id=1CgTtWiWeFrURT_Bs35aNWgO4MrCQPliN
CSP-XTRPOE16-4KS	https://drive.google.com/open?id=1CgTtWiWeFrURT_Bs35aNWgO4MrCQPliN
CSP-XTRNVR16-4KS	https://drive.google.com/open?id=1CgTtWiWeFrURT_Bs35aNWgO4MrCQPliN
CSP-XTRNVR32-4KS	https://drive.google.com/open?id=1CgTtWiWeFrURT_Bs35aNWgO4MrCQPliN
CSP-XTRNVR64-4KS2	https://drive.google.com/open?id=1-A_vk9q5x9PJwMK7Cv6XdG6xvJB1zEZ3

.

SureVision 2019 + Purchase Dates
NVR
SV-NVR2P8	https://drive.google.com/open?id=1IXTMXDH6Ts25SmYsCsJ5oRTH8fn5_4ka
SV-NVR4P16	https://drive.google.com/open?id=1c_y7YGxE_DY2kq8GEdkaoFE4kR-jwOfR
SV-NVR832	https://drive.google.com/open?id=1c_y7YGxE_DY2kq8GEdkaoFE4kR-jwOfR
SV-NVR864	https://drive.google.com/file/d/1t-OALXUz5uMujSi9iNUiWPDNBF__eXgF/view?usp=sharing

IMPORTANT: If you are having difficulty identifying the correct firmware please email us at support@cctvsecuritypros.com with your order number and unit model number.

.
